Semi-Concealed Framed Window with Integrated Screen

Semi-Concealed Framed Window with Integrated Screen

Semi-Concealed Framed Window with Integrated Screen - Image 2

Semi-Concealed Framed Window with Integrated Screen - Image 3

Semi-Concealed Framed Window with Integrated Screen - Image 4

Semi-Concealed Framed Window with Integrated Screen - Image 5

Category Windows Series Tags integrated screen, outword opening Brand: Asiland

All Custom Options Available!

Additional information

Model	AWS106/116/126
Opening Type	Outward Opening (Side-Hung)+Screen Sash
Fabrication Process	Mechanical Corner Crashing + Sealant Injection
Profile Thickness	1.8mm
Glass Configuration	5+15A+5(mm)/5+15A+5+15A+5(mm)
Glass Rebate	25mm/35mm/45mm/55mm
Hardware	CMECH High-Performance System
Thermal Break	PA66GF25 polyamide composite(multi-chamber) thermal break bar
Seal System	EPDM Automotive-Grade Seals
Standard Inclusion	Window Restraint Cable
Thermal Insulation	Class 4/6/8
Sound Insulation	Class 3/4
Water Tightness	Class 6
Air Permeability	Class 8
Wind Load Resistance	Class 9

Short Description

Integrated Semi-Concealed Frame Window with Screen Sash

Screen-integrated semi-concealed windows feature flush-to-wall frames for modern aesthetics. Reinforced construction resists Class 9 winds and earthquakes, while child-safe designs prevent falls. Smooth sealing ensures waterproofing and quiet operation.
